Self Loading All-in-One Stacker Fully Electric Lifting Capacity 500Kg, 1.6m Lifting Height PNXFESLS-0516 - Pronix

The Pronix Fully Electric Self Loading Stacker PNXFESLS-0513 is a compact, efficient, and reliable material handling solution designed for light to medium-duty warehouse and industrial operations. With a lifting height of 1.6 meters and a load capacity of 500 kg, this electric stacker delivers smooth and effortless lifting for a wide range of applications.

Powered by a DC drive and lift motor, the PNXFESLS-0513 ensures consistent performance and energy efficiency, while the 15 Ah lithium battery offers long-lasting operation with minimal maintenance. Its walking-type operation and durable wheel design provide superior maneuverability and control in confined spaces.

Built with robust materials and precision engineering, this self-loading stacker offers dependable handling of goods, making it ideal for use in warehouses, factories, workshops, and retail storage areas. Lightweight yet strong, it enhances productivity and reduces operator fatigue, making it an excellent choice for businesses seeking an efficient and easy-to-operate stacking solution.

Specifications

  • Brand - Pronix
  • Type - Fully Electric Self-Loading Stacker
  • Model - PNXFESLS-0516
  • Capacity - 500 Kg
  • Load Center Distance - 500mm
  • Fork Outer Spacing - 685mm
  • Fork Length - 1195mm
  • Operation Type - Walking Type
  • Forward & Backward - Electric
  • Lifting Up & Down - Electric
  • Drive Wheel Size - Ø 250 x 74 mm
  • Load Wheel Size - Ø 80 x 60 mm
  • Middle Wheel - Ø 65 x 30 mm
  • Fork Lift Height - 1600mm
  • Fork Starting Height from the Ground - 81mm
  • Wheel Base - 974mm
  • Vehicle Length - 1650mm
  • Body Thickness - 409mm
  • Body Width - 658mm
  • Front Track - 518mm
  • Single Fork Width - 253mm
  • Minimum Turning Radius - 1173mm
  • Maximum Driving Speed (Turtle Speed) - 0.5 km/h
  • Maximum Driving Speed (Full Load) - 3.0 km/h
  • Motor - DC 0.6 kW
  • Lift Motor - DC 2.2 kW
  • Battery - Lithium Battery (48 V)
  • Battery Capacity - 15 Ah
  • Battery Weight - 5 Kg
  • Overall Weight (Include Battery) - 382 Kg

Description

  • Pronix Fully Electric Self Loading Stacker 500Kg with Lifting Height 1.6m PNXFESLS-0513 is a highly durable and powerful stacker suitable for various commercial purposes.
  • Its maximum load capacity of 500 Kg and load center distance of 500mm allows for efficient transportation of heavy materials.
  • It has an operating type of walking-type, drive wheel size of Ø 250 x 74 mm, load wheel size of Ø 80 x 60 mm, and a maximum driving speed of 3.0 km/h.
  • The stacker is powered by a DC 0.6 kW motor and a DC 2.2 kW lift motor and supports a lithium battery of 15 Ah.
  • The durable construction and lithium battery provide reliability and a weight of only 5kg.
  • This stacker is perfect for warehouses and factories.
