Self Loading All-in-One Stacker Semi-Electric Lifting Capacity 1000Kg, 1.3m Lifting Height PNXSESLS-1013 - Pronix

The Pronix Semi-Electric Self Loading Stacker PNXSESLS-1013 is a compact yet powerful material handling solution designed for efficiency and versatility in warehouse and industrial operations. With a load capacity of 1000 kg and a lifting height of 1.3 meters, it provides reliable performance for stacking, loading, and transport applications.

Equipped with a 0.6 kW DC drive motor and a 2.2 kW DC lift motor, the stacker ensures smooth and controlled operation, while the lithium battery system delivers long-lasting power with minimal maintenance. Its compact frame—featuring a body width of 658mm and thickness of 409mm—enables effortless maneuvering in confined spaces.

With a minimum turning radius of 1173mm, the PNXSESLS-1013 offers exceptional control and mobility. Built to perform in demanding environments, this semi-electric stacker is a reliable choice for businesses seeking durability, safety, and operational efficiency in their material handling processes.

Specifications

  • Brand - Pronix
  • Type - Semi-Electric Self-Loading Stacker
  • Model - PNXSESLS-1013
  • Capacity - 1000 Kg
  • Load Center Distance - 500mm
  • Fork Outer Spacing - 685mm
  • Fork Length - 1195mm
  • Operation Type - Walking Type
  • Forward & Backward - Manual
  • Lifting Up & Down - Electric
  • Drive Wheel Size - Ø 250 x 74mm
  • Load Wheel Size - Ø 80 x 60 mm
  • Fork Lift Height - 1300mm
  • Fork Starting Height from the Ground - 81mm
  • Wheel Base - 974mm
  • Vehicle Length - 1650mm
  • Body Thickness - 409mm
  • Body Width - 658mm
  • Front Track - 518mm
  • Single Fork Width - 253mm
  • Minimum Turning Radius - 1173mm
  • Maximum Driving Speed (Turtle Speed) - 0.5 km/h
  • Maximum Driving Speed (Full Load) - 3.0 km/h
  • Motor - DC 0.6 kW
  • Lift Motor - DC 2.2 kW
  • Battery - Lithium Battery (48 V)
  • Battery Capacity - 15 Ah
  • Battery Weight - 5 Kg
  • Overall Weight (Include Battery) - 382 Kg

Description

  • Pronix Semi-Electric Self Loading Stacker 1000Kg PNXSESLS-1013 is a versatile stacker with a maximum load capacity of 1000Kg and a lifting height of 1.3m.
  • Its DC motor of 0.6kW and DC lift motor of 2.2kW provide smooth operation and the lithium battery ensures a powerful, long-lasting performance.
  • Its compact construction with a body thicknes of 409mm and body width of 658mm offers superior maneuverability and a minimum turning radius of 1173mm.
  • This semi-electric self-loading stacker is built to suit the toughest environments.
